Destination Charge $995
Dealer sets the actual destination charge, your price may vary.
Specifications and pricing are subject to change.
|Engine||695cc, liquid-cooled, 4-stroke, SOHC 4-valve-per-cylinder single|
|Bore x Stroke||102.0 x 85.0 mm|
|Fuel System||Fuel injection: ø44 mm x 1|
|Ignition||Battery & coil|
|Lubrication||Forced lubrication, wet sump|
|Transmission||Dual-range (high/low) CVT with centrifugal clutch and reverse|
|Final Drive||2WD/4WD, shaft, dual-mode differential|
|Frame||Ladder type, tubular steel|
|Front Suspension / Wheel Travel||Double wishbone / 218 mm (8.6 in)|
|Rear Suspension / Wheel Travel||Double wishbone / 232 mm (9.1 in)|
|Steering||Rack and pinion with Electric Power Steering|
|Rake / Trail||5.0° / -|
|Steering Angle (L/R)||40° (IN) / 30° (OUT), 40° (IN) / 30° (OUT)|
|Front Tires||25 x 8.00R12|
|Rear Tires||25 x 10.00R12|
|Front Brakes||Dual ø212 mm discs with two-piston calipers|
|Rear Brakes||Dual ø212 mm discs with single-piston calipers|
|Parking Brake||Dual discs (mechanical)|
|Dimensions (LxWxH)||2,795 x 1,525 x 1,925 mm (110.0 x 60.0 x 75.8 in)|
|Wheelbase||2,005 mm (78.9 in)|
|Road Clearance||270 mm (10.6 in)|
|Seat Height||850 mm (33.5 in)|
|Curb Mass**||723 kg (1,594 lb)|
|Fuel Capacity||36 litres|
|Tread (F/R)||1,322 mm (52.0 in) / 1,285 mm (50.6 in)|
|Turning Radius||4.2 m (13.8 ft)|
|Cargo Bed Dimensions (LxWxH)||847 x 1,119 x 232 mm (33.3 x 44.1 x 9.1 in)|
|Cargo Bed Capacity||317 kg (700 lb)|
|Vehicle Load Capacity||544 kg (1,200 lb)|
|Towing Capacity||680 kg (1,500 lb)|
|Lighting||2x halogen, 2x LED headlights|
|Instrumentation||Multi-function display includes driving mode (2WD/4WD) indicator, digital speedometer, digital fuel gauge, clock, odometer, dual trip meters, hour meter, differential indicator lamp, and various warning lamps|
|Kawasaki Protection Plus||12 / 24 / 36 / 48 months|
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2020 Canadian Kawasaki Motors, Inc.
Specifications subject to change.
