|Engine||636cc, liquid-cooled, 4-stroke, DOHC 16-valve in-line four|
|Bore x Stroke||67.0 x 45.1 mm|
|Fuel System||Fuel injection: ø38 mm x 4 with oval sub-throttles|
|Lubrication||Forced lubrication, wet sump|
|Clutch||Wet multi-disc, manual|
|Front Suspension / Wheel Travel||ø41 mm inverted fork (SFF-BP) with rebound and compression damping and spring preload adjustability / 120 mm (4.7 in)|
|Rear Suspension / Wheel Travel||Bottom-Link Uni Trak, gas-charged shock with piggyback reservoir, compression and rebound damping and spring preload adjustability / 151 mm (5.9 in)|
|Rake / Trail||23.5° / 101 mm|
|Steering Angle (L/R)||27° / 27°|
|Front Tire||120/70ZR17M/C (58W)|
|Rear Tire||180/55ZR17M/C (73W)|
|Front Brakes||Dual semi-floating ø310 mm petal discs with radial-mount, monobloc, opposed 4-piston calipers|
|Rear Brake||ø220 mm petal disc with single-bore pin-slide aluminum-piston caliper|
|Dimensions (L x W x H)||2,025 x 710 x 1,100 mm (79.7 x 28.0 x 43.3 in)|
|Wheelbase||1,400 mm (55.1 in)|
|Road Clearance||130 mm (5.1 in)|
|Seat Height||830 mm (32.7 in)|
|Curb Mass**||195 kg (430 lb)|
|Fuel Capacity||17 litres|
|Instrumentation||Analogue-style tachometer + warning lights and multi-function LCD screen with gear position indicator, shift indicator, digital speedometer, odometer, dual trip meters, fuel gauge, remaining range, current and average fuel consumption, intake air temperature, coolant temperature (displayed as a bar graph, and also available numerically), clock (12h or 24h display), Power Mode and KTRC indicators, KQS indicator, KIBS indicator*, and the Economical Riding Indicator (*on ABS model)|
|Kawasaki Protection Plus||12 / 24 / 36 / 48 months|
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2020 Canadian Kawasaki Motors, Inc.
Specifications subject to change.
