TERYX KRX4 1000 eS SPECIAL EDITION

4-PASSENGER SPORT SIDE X SIDE FOR OFF-ROAD ADVENTURES

  • MSRP
    TBA

Specifications and pricing are subject to change.

Sky Blue / Ebony

Sky Blue / Ebony

Kawasaki Electronic Control Suspension with
FOX 2.5 Live Valve Internal Bypass shocks
7" full-colour TFT instrumentation with
Smartphone Connectivity

Click on a technology to learn more.

Power 82.1 kW {112 PS} / 8,500 rpm
Torque 102 Nm {10.4 kgfm} / 7,000 rpm
Engine 999cc, liquid-cooled, 4-stroke, DOHC 4-valve-per-cylinder parallel twin
Bore x Stroke 92.0 x 75.1 mm
Compression Ratio 11.5:1
Fuel System Fuel injection: ø50 mm x 2
Ignition Digital
Starting Electric
Lubrication Forced lubrication, wet sump
Transmission Dual-range (high/low) CVT with centrifugal clutch and reverse
Final Drive 2WD/4WD, shaft
Frame Ladder type, tubular steel
Front Suspension / Wheel Travel Double wishbone, FOX 2.5 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually-adjustable spring preload / 472 mm (18.6 in)
Rear Suspension / Wheel Travel 4-Link Trailing Arm rear suspension, FOX 2.5 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually-adjustable spring preload / 536 mm (21.1 in)
Steering Rack and pinion with Electric Power Steering
Rake / Trail 10.0° / 65 mm
Steering Angle (L/R) 34° (IN) / 29° (OUT), 34° (IN) / 29° (OUT)
Front Tires MAXXIS Carnivore 31 x 10.00R15 8PR
Rear Tires MAXXIS Carnivore 31 x 10.00R15 8PR
Front Brakes Dual ø258 mm discs with twin-piston (ø32 mm x2) calipers
Rear Brakes Dual ø258 mm discs with single-piston (ø38 mm x1) calipers
Parking Brake Auto-adjust mechanical disc
Dimensions (LxWxH) 3,995 x 1,730 x 1,935 mm (157.3 x 68.1 x 76.2 in)
Wheelbase 3,195 mm (125.8 in)
Road Clearance 360/385 mm (standard/max preload) (14.2/15.2 in (standard/max preload))
Seat Height 820 (F) / 830 (R) mm (32.3 (F) / 32.7 (R) in)
Curb Weight* 956 kg (2,108 lb)
Estimated Dry Weight** 910 kg (2,006 lb)
Fuel Capacity 40 litres
Tread (F/R) 1,505 mm (59.3 in) / 1,480 mm (58.3 in)
Turning Radius 7.1 m (23.3 ft)
Cargo Bed Dimensions (LxWxH) 370 x 840 x 230 mm (14.6 x 33.1 x 9.1 in)
Cargo Bed Capacity 159 kg (351 lb)
Seating Capacity 4
Vehicle Load Capacity 454 kg (1,000 lb)
Lighting 2x LED headlights
Instrumentation 7” high-grade full-colour TFT LCD screen with speedometer, tachometer, fuel gauge, gear indicator (L, H, N, R), Driving Mode (2WD/4WD/4WD+Diff Lock), Power Mode (Full/Low), Suspension Mode (Soft/Normal/Firm), clock, CVT temperature; selectable display that includes: digital tachometer, odometer, dual trip meters, total time, trip time, average speed, water temperature, battery voltage; Economical Riding Indicator, maintenance reminder (2 driver-selectable reminders), and a range of indicators and warning lamps
Warranty 6 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months

*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2020 Canadian Kawasaki Motors, Inc.

Specifications subject to change.
