Special Edition Color - Candy Plasma Blue ($10,699 MSRP)
Specifications and pricing are subject to change.
MODEL SPECS |
Click on a technology to learn more.
Engine Management Technology |
Chassis Management Technology |
Power | 92 kW {125 PS} / 9,500 rpm |
Torque | 99 N. m {10.1 kgf. m} / 7,700 rpm |
Engine | 4-stroke, In-Line Four |
Displacement | 948cc |
Bore x Stroke | 73.4 x 56.0 mm |
Compression Ratio | 11.8:1 |
Valve System | DOHC, 16 valves (4 valves per cylinder) |
Fuel System | 36 mm x 4 with sub-throttles |
Ignition | Digital |
Cooling | Liquid |
Lubrication | Forced lubrication (wet sump) |
Transmission | 6-speed, return |
Primary Reduction Ratio | 1.627 (83/51) |
Gear Ratio: 1st | 2.692 (35/13) |
Gear Ratio: 2nd | 2.059 (35/17) |
Gear Ratio: 3rd | 1.650 (33/20) |
Gear Ratio: 4th | 1.409 (31/22) |
Gear Ratio: 5th | 1.222 (33/27) |
Gear Ratio: 6th | 1.034 (30/29) |
Final Reduction Ratio | 2.933 (44/15) |
Clutch | Wet multi-disc, manual |
Final Drive | Chain |
Frame | Trellis, high-tensile steel |
Front Suspension / Wheel Travel | 41mm inverted fork with rebound damping and spring preload adjustability/4.7 in |
Rear Suspension / Wheel Travel | Horizontal back-link, stepless rebound damping, adjustable spring preload/5.5 in |
Front Suspension | 41 mm inverted fork with rebound damping and spring preload adjustability |
Rear Suspension | Horizontal Back-link with rebound damping and spring preload adjustability |
Front Wheel Travel | 120 mm (4.7 in.) |
Rear Wheel Travel | 140 mm |
Rake | 24.5° |
Trail | 110 mm |
Steering Angle (L/R) | 33° / 33° |
Front Tire | 120/70-ZR17M/C (58W) |
Rear Tire | 180/55-ZR17M/C (73W) |
Front Brakes | Dual semi-floating 300 mm petal discs |
Front Calipers | Dual opposed 4-piston |
Rear Brake | Single 250 mm petal disc |
Rear Caliper | Single-piston caliper |
Overall Length | 2,070 mm |
Overall Width | 825 mm |
Overall Height | 1,080 mm |
Wheelbase | 1,455 mm |
Wheelbase | 1,455 mm |
Road Clearance | 145 mm |
Seat Height | 820 mm |
Curb Mass** | 212 kg** |
Fuel Capacity | 17 litres |
Warranty | 12 months warranty |
Final drive | Chain |
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2020 Canadian Kawasaki Motors, Inc.
Specifications subject to change.
