Engine	84cc, liquid-cooled, 2-stroke single with KIPS
Bore x Stroke	48.5 x 45.8 mm
Compression Ratio	10.9:1 (low speed), 9.0:1 (high speed)
Induction	Piston reed valve
Fuel System	Carburettor: Keihin PWK28
Ignition	Digital-CDI
Starting	Primary kick
Lubrication	Pre-mix (32:1)
Transmission	6-speed, return
Clutch	Wet multi-disc, manual
Final Drive	Chain

Frame	Perimeter, high-tensile steel
Front Suspension / Wheel Travel	ø43 mm inverted fork with adjustable compression and rebound damping / 275 mm (10.8 in)
Rear Suspension / Wheel Travel	Uni-Trak, single shock with adjustable dual-range (high/low-speed) compression damping, adjustable rebound damping and adjustable spring preload / 305 mm (12.0 in)
Rake / Trail	29.2° / 117 mm
Steering Angle (L/R)	39° / 39°
Front Tire	70/100-19 42M
Rear Tire	90/100-16 51M
Front Brake	ø240 mm petal disc with dual-piston caliper
Rear Brake	ø220 mm petal disc with single-piston caliper

Dimensions (L x W x H)	1,935 x 800 x 1,165 mm (76.2 x 31.5 x 45.9 in)
Wheelbase	1,310 mm (51.6 in)
Road Clearance	330 mm (13.0 in)
Seat Height	865 mm (34.1 in)
Curb Weight*	78.2 kg (172 lb)
Weight Without Fuel	74.6 kg (164 lb)
Fuel Capacity	5.0 litres

*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2020 Canadian Kawasaki Motors, Inc.

Specifications subject to change.
